详细介绍
| Model No. | Power(HP) | Speed(RPM) | Arm Volt | NEMA Frame | ENCL. | Curret(Amp.) | Torque(In.Ibs) | App Weight(Ibs) |
| MD85BY | 1/5 | 500 | 220 | TENV | 1.2 | 25.8 | 16.7 |
| Dimension Chart (All Dimensions in Inch.) | ||||||||
| Model No. | U | AH | BB | AK | AJ | TAP | BD | C |
| MD85BY | 0.551 | 1.24 | 0.0787 | 2.874 | 3.858 | 0.256 | 3.35 | 5.81 |
|
|
|
|
详细介绍
| Model No. | Power(HP) | Speed(RPM) | Arm Volt | NEMA Frame | ENCL. | Curret(Amp.) | Torque(In.Ibs) | App Weight(Ibs) |
| MD85BY | 1/5 | 500 | 220 | TENV | 1.2 | 25.8 | 16.7 |
| Dimension Chart (All Dimensions in Inch.) | ||||||||
| Model No. | U | AH | BB | AK | AJ | TAP | BD | C |
| MD85BY | 0.551 | 1.24 | 0.0787 | 2.874 | 3.858 | 0.256 | 3.35 | 5.81 |
